ECUMaster PMU16 Autosport Power Management Unit
- SKU:
- ECUPMU16AS
We want to be your only stop for quality auto racing parts, and we recognize that our customers may need some assistance in choosing the right products. After all, nobody is born an expert.
As knowledgeable racing enthusiasts, we are happy to offer our professional advice, quotes, and assistance over the phone.
If you need information or advice on the latest Nissan aftermarket parts, or if you have any questions at all, please feel free to give our friendly experts a call at (352) 241-8399 or send us an email at [email protected]
Working Hours:
- Monday 11AM - 5PM EST
- Tuesday - Friday 10AM - 5PM EST
- Closed for lunch daily, 12:30PM - 1:30PM EST
Questions? Contact our experts at (352) 241-8399 or send us an email.
The ECUMasterA brand has quickly become popular for delivering excellent
value and performance. This ethos was noticed by high caliber
motorsport customers and OEMs ,A which created a need for motorsport gradeA products. We would like to introduce
the new PMU16 AS, a motorsport grade power distribution module built for the most demanding customers and applications.
The PMU16 Autosport Version is designed for demanding customers
and installations where reliability and robustness are top priorities.
Autosport connectors represent the highest quality connector
available, and are the standard for professional motorsports and
aerospace industries. The battery connection utilizes a RadlokTM
connector rated to 200 amps that can be disconnected without the need
for any tools. The output connector is a custom 18 pin, 12 gauge
connector designed and manufactured specifically for Ecumaster. The
unit features an IP65 environmental protection rating, permitting its
use in the harshest of conditions, including dusty and wet
environments.
Compared to the standard PMU16, 6 low side outputs have been added
and are rated at 2 amps per channel. 14 of the main output channels
are rated at 25 amps, with two output channels rated at 40 amps.
As always with Ecumaster products, mating connectors and terminals
are included at no extra cost, which represents a substantial savings
and saves the hassle of ordering separate components.
NOTE: There are no returns for any ECU Masters ECU
WHAT'S IN THE BOX?
- PMU16 AutoSport Device
- Two Autosport Connectors with Terminals
- Radlok connector for power input
- Laminated Pinout Card
RECOMMENDED ACCESSORIES
- USB to CAN Adapter (you may use a Peak PCAN or Kvaser CAN cable, but one of these three USB to CAN interfaces must be used to program the device)
CAN Keyboard (mechanical switches may be connected to any of the 16 analog inputs, but CAN keyboards add functionality to the PMU16)
PMU16 USER MANUALA A
PMU16 SOFTWAREA A (scroll down to PMU section)
Legal only for use in competition vehicles which may never be registered, licensed, and/or used on public streets or highways; and also for use in other exempted vehicles.
